RINGFEDER - RFN 7013.1-20x47

Details

(THREAD = M6 x 20), These flange type units fix the hub positively against their extended flange preventing axial movement during tightening. Applied wherever self-centering action and good concentricity of mounted components are essential and hubs with straight-thru bores are used. Features are : High rotation speed, High radial loads, Axial hub positioning, High torque, Excellent concentricity and very easy to dismantle - these Locking As­sem­blies provide particularly good concentricity between the clamped parts. The flange is reinforced at the critical point, preventing bending or lifting of the inner ring during assembly and thereby ensuring easy dismantling.

Specifications
