Neutral - B206 | Overruning Clutches | 32.76 × 62 × 28 mm

Details

Neutral B206 is an overruning clutches with inner diameter 32.76 mm, outer diameter 62 mm and width 28 mm. Additional specifications include bore type CYLINDRICAL, cage YES and lubrication STANDARD.

This record lists Neutral B206 as part of the Overrunning Clutches range under Clutch and Brakes. The product record shows size 32.76 × 62 × 28 mm, cylindrical bore, cage available, standard lubrication and weight 0.68 kg. Compare this record with applications such as maintenance replacement of pillow-block, flange and take-up style bearing locations, focusing on shaft size, bolt pattern and housing style. Final suitability should be checked from the machine drawing or existing component. Catalogue note: B206 is a sprag type freewheel non-bearing supported and non-inner race clutch. Nominal diameter is a standard ball bearing dimension. Bearings are required to support axial and radial loads. Units are delivered grease lubricated. The outer race is keyed to the housing, because sprag contact to shaft directly, the shaft must have the hardness HRC 56 - 60 and tolerance h7. This series extensive used in machinery system of conveyor, hosting, packaging, printing papermaking corrugated and food machinery etc.

Specifications
