WD BEARING - AP4-Q | Flange Plates | 80 × 120 × 120 mm

Details

WD BEARING AP4-Q is a flange plates with inner diameter 80 mm, outer diameter 120 mm and width 120 mm.

WD BEARING AP4-Q is listed in the Flange Plates range under Special Bearings with VW Impex product serial 195480. Recorded specification details include size 80 × 120 × 120 mm and PDF reference available. This mounted bearing or housing unit provides a mounted support point for a rotating shaft and is normally reviewed for conveyors, fans, processing machinery and general rotating equipment. Before ordering, confirm shaft size, bolt pattern and housing style against the equipment manual, existing part marking or technical drawing. Catalogue note: Square flange plate designed for mounting combined bearings WD Bearing. The AP series flange plate is commonly employed in heavy-duty linear guidance systems, including those found in material handling applications. Material: Outer rings and axial rollers are made of case-hardening steel (20CrMnTi) with a hardness of 58-62 HRC. Inner rings and pins are made of core-hardened 100 Cr6 steel.

Specifications
