WD BEARING - AP4 | Flange Plates | 80 × 180 × 120 mm

Details

WD BEARING AP4 is a flange plates with inner diameter 80 mm, outer diameter 180 mm and width 120 mm.

This record lists WD BEARING AP4 as part of the Flange Plates range under Special Bearings. The product record shows size 80 × 180 × 120 mm and PDF reference available. Compare this record with applications such as maintenance replacement of pillow-block, flange and take-up style bearing locations, focusing on shaft size, bolt pattern and housing style. Final suitability should be checked from the machine drawing or existing component. Catalogue note: Combination of a flange plate and a combined bearing from the WD Bearing. It is crucial to understand that itself is a flange plate, designed to work in conjunction with a bearing, often a combined bearing, to create a robust system for handling heavy loads and providing linear motion. Combined bearing. Combined bearings are designed to handle both radial and axial loads simultaneously. Materials: Outer ring: case-hardened steel (20 CrMnTi); Inner ring: bearing steel (100 Cr 6). Features are : Dual Load-Bearing.
