RINGFEDER - TNB BHDD - 500 | Couplings Units | 500 × 608 mm

Details

RINGFEDER TNB BHDD - 500 is a couplings units with outer diameter 500 mm and width 608 mm. Additional specifications include bore type CYLINDRICAL.

This record lists RINGFEDER TNB BHDD - 500 as part of the Couplings Units range under Couplings. The product record shows size outer diameter 500 mm, width 608 mm, cylindrical bore, weight 380 kg and PDF reference available. Compare this record with applications such as maintenance replacement on mechanical power-transmission systems, focusing on bore size, hub style and element type. Final suitability should be checked from the machine drawing or existing component. Catalogue note: Multi-part design with radially removable central section and VkR buffer. Easy assembly of the drive train due to the insertable central section. The RINGFEDER TNB BHDD - coupling is a torsionally flexible, puncture proof claw coupling. It compensates for angular, radial and axial shaft misalignments within defined limits. The coupling transmits torque through elastic buffers loaded in shear. These buffers come in synthetic rubber (Pb) or polyurethane (Vk), as a standard VkR. These elastic buffers dampen shocks.

Specifications
