NSK - W1601MA-1PY-C3Z2

Details

(1 NUT + 1 SCREW), Size 16X2

NSK Ball Screw, Bridge Deflector, Series: MA Series, 16 mm Screw Dia, 2 mm Thread Lead, Right Hand Thread, 14.6 mm Root Dia, 100 mm Length, 1 Start, Steel

The W1601MA‑1PY‑C3Z2 is part of NSK's MA Series of miniature ball screws. It features precision-ground construction and integrates a bridge deflector system for smooth ball recirculation.

Bridge Deflector Circulation: Ensures reliable ball recirculation without external return tubes.

Precision and Rigidity: Designed for high-precision linear actuation—popular in CNC, automation, semiconductor, and injection molding industries.

The NSK W1601MA‑1PY‑C3Z2 is a high-precision, 16 mm, 2 mm lead, single-start, right-hand ball screw of C3 accuracy, with bridge deflector design in a 100 mm length unit. Built for precision and smooth operation with a machined standard shaft design for compatibility with support units.

Specifications
