NADELLA - C4 RCL 16 NX

Details

Nadella roller linear guide carriage used in motion technology systems for light to medium loads. It is not a single, standalone bearing but a complete carriage assembly that uses guide rollers. A carriage plate with a body made of anodised aluminum that is fitted with four guide rollers. Materials: The carriage body is extruded and hard-anodized aluminum for wear and corrosion protection, while the guide rollers are made of corrosion-resistant bearing steel. Features are : High Speeds, Low Noise and Smooth Motion, Load Management, Tolerance Compensation, High Dynamics, Integrated Lubrication System, Operating Temperatures. Applications : Robotics and Manipulators, Conveyor and Transfer Systems, Automatic Warehousing, Packaging Machinery, Machine Tools, Woodworking Machinery, Printing Machines, Medical and Electro-medical Machines, Food Processing, Measuring Instruments. RCL: Designates the specific series of guide rollers used, which have a gothic arch profile and are based on angular contact ball bearings, NX: This suffix indicates that the guide rollers are made of stainless steel (corrosion-resistant bearing steel).

Specifications
