TBI MOTION TECHNOLOGY CO., LTD., is a specialized manufacturer in linear motion products in Taiwan, possessing critical core technology and concentrating on product research and innovative design. Our products are under patent design with ISO 9001:2008 certification and now distributors have been established all over the world since 1986. With “outstanding quality, high capacity”, we are well recognized in the market. We have full production lines and all the products are made in Taiwan. Our main products are Ball Screw, Linear Guide, Ball Spline, Precision Ball Screw / Spline, Single Axis Actuator, Linear Ball Bearing, Coupling, Support Unit…etc. The range of applications of our products is as follows: Automatic controlling machine; Robot Industry; Semi-conductor Industry; General Industrial Machinery; Medical equipment; Solar energy equipment; Machine Tool; and Parking System.
Extensive range of TBI Motion linear guides offer precision and quality at competitive prices suitable for most automation requirements. The design of TBI Motion linear guide rails and block features an equal lead rating in all four directions that request sufficient rigidity load in all directions, and self-aligning capability to absorb installation-error. Moreover, a sufficient preload can be achieved to increase rigidity and makes it suitable for any kind of installation.
TBI Motion range of ball screw assemblies offer a choice of screw diameters and pitches to suit a wide variety of applications. All single nuts are offered play free. To further compliment the range there are high lead and miniature ball screws. Rigidly selected materials, intensive heat treating and processing techniques, backed by years of experience,have resulted in the most durable ball screws manufactured. With proper lubrication and use,trouble-free operation for an extended period of time is possible.
The design of TBI Ball spline is to utilize the friction force through the contact of steel balls within in the Spline Nut and the grooves on the Spline Shaft. With TBI MOTION’s unique 40° angular contact design which enables the Ball spline delivers high sensitivity and extreme high load carrying capacity. The concept is optimal for the application involve with high speed, vibrates, impacts of loading and precise positioning requirements. Also when the Ball spline is used to function as linear bushing, the Ball spline provides ten times loading capacity than the linear bushing in the like dimensioned but with a compact profile. Namely, Durability and reliablility is the reason for choosing TBI Ball spline in your application. TBI MOTION Spline Nut is available in two different designs: SLF (Flange design) and SLT (Non-flange design). Point of contacts on the Spline shaft is provided in two grooves (180°) (SLF/SLT6~20) and four grooves (70°) (SLF/SLT25~50) base on the diameter of the Spline shaft. Also TBI provides Hollow Spline shaft for alternative.
