With operations in almost 20 countries, and an international network of distribution partners, you can depend on Renold to provide specific solutions to customer's unique problems, with unrivalled local support.
Renold ranges of industrial chain, gearboxes , cluctch and couplings are specified for use in power transmission, lifting, conveying and processing applications around the world.
Tackling thousands of demanding operating environments, Renold has a track record of success and innovation offering many unique products and services.
• All clutches are fitted with high precision heavy duty bearings for arduous duty applications
• Clutch sizes 300 to 700 are fitted with ARO sprags to resist vibration and high transient torques and overloads
• SO series clutches, oil lubricated suitable for overrunning, backstopping and medium duty indexing (up to 150 indexed/minute)
Renold REUS Series Trapped Roller Freewheels are non self-centering. Bearings must be placed adjacent to the freewheel to ensure concentricity between inner and outer races.
The REUS Series freewheels have the same outside dimensions as standard 62 series bearings
The REUK Series is a Freewheel incorporating a 62 Series bearing.
The self-centering freewheels are already grease-lubricated and come with dust-proof protection.
For the REUK model, the transmission occurs by mounting the inner race onto a shaft with an n6 tolerance. The outer race is fitted into a housing with an N6 tolerance.
Renold REUSNU Series Trapped Roller Freewheels are non self-centering. Bearings must be placed adjacent to the freewheel to ensure concentricity between inner and outer races.
The REUSNU Series freewheels have the same outside dimensions as standard 63 series bearings.
Renold REUF Series Trapped Roller Freewheels are non self-centering. Bearings must be placed adjacent to the freewheel to ensure concentricity between inner and outer races.
The REGL F2-D2 (or D3) series comprises an REGL Base Unit freewheel, combined with an F2 Fixing Flange and a D2 (or D3) Cover Flange.
The REGL F4-D2 series comprises an REGL Base Unit freewheel, combined with an F4 Fixing Flange and a D2 Cover Flange.
DM series direct mounting sprag clutches are specifically designed for use as backstops in applications where compact dimensions are required.
The clutch is designed to fit in a housing with the shaft as the inner race. This type is particularly suitable for use in gear units and similar equipment where good concentricity between shaft and housing is ensured.
Renold SO Sprag Clutch Torque Arms are made specifically for use in conjunction with Renold SO sprag clutch freewheels.
Stub shaft adaptors for use with SO and SX sprag clutches providing a mounting stub shaft for mechanical elements such as chainwheels, couplings, gears, pulleys, cams, levers, etc, when the size or configuration of these parts does not allow bolting holes to be drilled to match the existing tapped holes in the clutch.
